MB-D(LE) 407 - 412 B07 GasMultiBloc Combined Regulator and Safety Shut-Off Valves Single-Stage Function Integrated Bypass Valve

Get a Price/Quote

MOQ : 1 Unit

MB-D(LE) 407 - 412 B07 GasMultiBloc Combined Regulator and Safety Shut-Off Valves Single-Stage Function Integrated Bypass Valve Specification

Connection Type
Flanged or threaded connections

Features
Integrated regulator and shut-off valve, test point, drive for closed position monitoring, integrated bypass, high tightness

Control System
Electrical-actuated with optional closed position signal feedback

Material
Aluminium body with brass/steel internal components

Valve Type
Single-stage, fast-closing

Valve Size
DN 40, DN 50, DN 65

Voltage
230V AC

Sealing
Soft seal, internal leakage-proof design

Application
Industrial and commercial gas burner systems, gas inlet section for modulating or on/off operation

Structure
Single-stage function with integrated bypass valve and pressure regulator

Type
GasMultiBloc Combined Regulator and Safety Shut-Off Valve

Power
230V AC, 50/60 Hz

Pressure
Inlet pressure: max. 360 mbar, Outlet pressure: 5 - 110 mbar (adjustable)

Media
Natural gas, LPG, air and non-aggressive gases

Port Size
DN 40 - DN 65

Temperature
-15C to +60C

Disc
Metal

Pin
Multi-pin plug connection as per DIN EN 175301-803

Serviceability
Modular construction for quick service or valve replacement

Flow Rate
Up to 412 m3/h (for DN 65, air/gas at 1 bar, p=20 mbar)

Bypass Function
Integrated - adjustable for precise pressure stability

Mounting Position
Any, preferably upright

Response Time
Less than 1 second

Regulator Type
Class A - with balanced valve seat and bleed impulse connection

Pressure Tapping Points
Provided before and after valves for manometer connection

Shut-off Valves
Two-valve design (V1 + V2) for maximum safety

Ambient Humidity
Up to 95% RH, non-condensing

Protection Class
IP54

MB-D(LE) 407 - 412 B07 GasMultiBloc Combined Regulator and Safety Shut-Off Valves Single-Stage Function Integrated Bypass Valve Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
7 Week

About MB-D(LE) 407 - 412 B07 GasMultiBloc Combined Regulator and Safety Shut-Off Valves Single-Stage Function Integrated Bypass Valve

Experience astounding performance with the MB-D(LE) 407 - 412 B07 GasMultiBloc Combined Regulator and Safety Shut-Off Valves. This decorated device is pivotal for modern industrial and commercial gas burner systems, offering unbeatable price and reliability for gas, LPG, or air operations. Features include a single-stage function, integrated bypass for precise pressure, rapid response time under 1 second, and high-level safety via two shut-off valves. Its modular construction ensures easy serviceability. Grab yours today to enjoy maximum protection, exceptional flow rates up to 412 m3/h, and IP54 robust design-try now and revolutionize your gas regulation needs.

Enhance Gas Burner Performance and Safety

The MB-D(LE) 407 - 412 B07 is widely used in industrial and commercial gas burner setups, serving as a decorated main regulator and safety shut-off valve. Its straightforward application method-mounting in any position, preferably upright-makes it user-friendly. Primary competitive advantages include its astounding integrated bypass valve, modular construction for swift service, and exceptional sealing against leaks. The two-valve safety design provides added security, setting it apart for cost-effectiveness and reliability.

Sample, Delivery, and Global Export Market Reach

Secure a sample of the MB-D(LE) 407 - 412 B07 GasMultiBloc for first-hand evaluation. With prompt delivery times and efficient processing, businesses can swiftly exchange and implement this advanced regulator. Our secure shipping practices ensure each valve reaches you in excellent condition. Serving major export markets globally, we specialize in supplying the Indian market as a reputable trader. Reach out and experience unparalleled quality and service, wherever your operations are located.

FAQ's of MB-D(LE) 407 - 412 B07 GasMultiBloc Combined Regulator and Safety Shut-Off Valves Single-Stage Function Integrated Bypass Valve:

Q: How is the MB-D(LE) 407 - 412 B07 installed and mounted?

A: This device can be mounted in any position, though upright installation is preferred for optimal performance. Its modular construction facilitates both straightforward initial placement and quick maintenance if needed.

Q: What are the key benefits of using the MB-D(LE) 407 - 412 B07 in gas burner systems?

A: The unit offers high safety, thanks to its two-valve shut-off system, fast response time (under 1 second), and precise pressure stability. These benefits, alongside compatibility with natural gas, LPG, and air, ensure efficiency and security.

Q: When can users expect prompt delivery and what regions are served?

A: We provide fast delivery times and ship securely to major export markets worldwide, focusing mainly on India but capable of handling global exchanges as a trusted supplier.

Q: What is the primary application method for this regulator and safety shut-off valve?

A: It is primarily applied in industrial and commercial burner systems, integrated into the gas inlet section for either modulating or on/off operation.

Q: How does the integrated bypass valve work in this product?

A: The integrated bypass valve allows for adjustable and precise pressure management, contributing to stable operation and optimal burner performance in various gas applications.
